Hastelloy C22 Flange

Specifications：ASTM B564 / ASME SB564
Size：1/2″ (15 NB) to 48″ (1200NB)
Type：TH (THreaded) flange, SO (Slip-On Welding) flange, BL (Blind) flange, SW (Socket Welding) flange, LJ (Lapped) flange, WN (Welding Neck) flange
Customized size and processing are supported
Payment way:T/T, L/C, can be negotitated"

Send Inquiry

Download

Product Description

Your Trusted Hastelloy C22 Flange Supplier

TSM Technology Co., Ltd is a leading manufacturer and supplier of Hastelloy C22 Flange, providing high-quality, corrosion-resistant flanges for industries such as chemical processing, aerospace, marine, and energy. With over 14 years of experience, we ensure strict quality control, competitive pricing, and reliable global supply.

What is Hastelloy C22 Flange?

Hastelloy C22 Flange is a nickel-based alloy flange known for its exceptional resistance to oxidation, pitting, crevice corrosion, and stress corrosion cracking. It is widely used in harsh environments where conventional stainless steel or lower-grade alloys fail.

Supply type

Standard type
Complies with ANSI/ASME B16.5, DIN and other standards, covers flat welding/butt welding/blind flanges, supports PN6-PN160 pressure levels and DN15-DN1200 conventional sizes.

Customized type
Produce large-diameter (≥1000mm), special-shaped structures or nuclear-grade thick-walled flanges according to drawings, supporting customized needs such as pickling, electrolytic polishing and sealing surface surfacing.

Material and process

Processing technology
Adopt free forging/die forging process, combined with solid solution annealing (1150-1180℃ water quenching) to optimize performance, and CNC finishing to ensure dimensional accuracy (tolerance ±0.1mm).

Quality inspection
Verified by ultrasonic flaw detection (UT) and penetrant testing (PT) without defects, in line with ASTM B564 and ASME SB-564 standards, provide material certificates and third-party certification.

Hastelloy C-22(UNS N06022/W.Nr.2.4602)

Chemical Composition

Alloy

C-22

min

margin

20.0

12.5

2.5

max

margin

22.5

14.5

0.0015

0.5

0.08

0.02

2.5

0.35

3.5

Physical Characteristics

Density

8.9g/cm³

Melting point

1325-1370℃

Minimum mechanical properties of alloys at room temperature

Typical mechanical properties

tensile strength Rm N/mm²

Yield Strength RP0.2 N/mm²

Elongation A5%

Test℃

Solution treatment

690

283

Room temperature

Material Characteristics

Corrosion Resistance: Excellent resistance to pitting, crevice corrosion, and stress corrosion cracking.

Oxidation Resistance: High-temperature performance in oxidizing environments.

Versatile Applications: Used in aggressive chemical environments such as hydrochloric acid and sulfuric acid.

Weldability: Easily welded with minimal carbide precipitation issues.

Applications of Hastelloy C22 Flange

Chemical Processing: Corrosive acid handling, reactors, piping systems

Aerospace & Defense: High-performance fuel and exhaust systems

Marine & Offshore: Saltwater-resistant components in ships and rigs

Energy & Power Plants: Heat exchangers, cooling systems, and pressure vessels

Medical & Pharmaceutical: Sterile and corrosion-resistant piping and equipment

Why Choose Us?

Custom Solutions

Tailor-made flanges based on specific industrial requirements.

Competitive Pricing

Cost-effective solutions with bulk order discounts.

Global Availability

Reliable and timely delivery worldwide.

Customer Support

Dedicated team for technical assistance and after-sales servi

FAQ

Q1: What types of Hastelloy C22 Flanges do you offer?

We provide:

Threaded (TH) Flange

Slip-On Welding (SO) Flange

Blind (BL) Flange

Socket Welding (SW) Flange

Lapped (LJ) Flange

Welding Neck (WN) Flange

Q2: Can I order custom sizes or specifications?

Yes! We offer customized sizes and processing based on your exact specifications.

Q3: What payment methods do you accept?

We accept T/T, L/C, and other negotiable payment terms.

Q4: Do you provide material test reports and certifications?

Absolutely! We provide full certification, including ISO 9001, ISO 14001, and ISO 45001, along with test reports.

Q5: How do I place an order?

Simply contact us via email or phone with your specifications, and our team will assist you.
