Nickel 200 Sheet

Standard:ASTM，JIS，AISI，GB，DIN，EN
Form:Plate,Sheet,Coils, Foils, Strip, Flats
Thickness:0.1 milimeter to 100 milimeter Thk
Technique：Cold rolling, hot rolling, solution, annealing
Customized size and processing are supported
Payment way:T/T, L/C, can be negotitated

Send Inquiry

Download

Product Description

Trusted Nickel 200 Sheet Manufacturer & Supplier

TSM Technology Co., Ltd is a premier supplier of Nickel 200 Sheet, providing high-quality, pure nickel materials tailored for industries requiring superior corrosion resistance and thermal stability. With over 14 years of expertise, we ensure consistent supply, strict quality control, and global delivery to meet your engineering and manufacturing needs.

Nickel 200 Sheet Introduction

Nickel 200 Sheet is a commercially pure wrought nickel alloy (99.6% nickel) known for its excellent mechanical properties, corrosion resistance, and thermal and electrical conductivity. This high-purity nickel alloy is ideal for industries such as chemical processing, aerospace, marine, and electronics, where durability and performance are critical.

Supply Type

The types of nickel 200 plates we supply mainly include sheet, plate, foil, and strip. Our products are widely used in chemical, petrochemical, aerospace, marine engineering and other fields to meet the diverse needs of different customers.

TSM nickel 200 sheet specifications and standards

Sheet: thickness 0.2~6mm, width ≤2000mm, length ≤6000mm;
Plate: thickness 6~50mm, width ≤2500mm, length ≤12000mm;
Foil: thickness 0.05~0.2mm, width ≤1000mm, supplied in rolls;
Strip: thickness 0.1~3mm, width ≤600mm, roll length customized.

Implementation standards:

ASTM B162 (plate/strip), ASTM B906 (foil), AMS 5553, EN 2.4060.

Surface and precision:

Surface: cold rolled polishing (Ra≤0.8μm), pickling, mirror finish;
Tolerance: thickness ±5%~±1%, customized according to specifications.

Incoloy 200(N02200/2.4060/Nickel200)
Brief introduction	Nickel 200 is pure commercial (99.6%) nickel with excellent mechanical properties and corrosion resistance, high thermal and electrical conductivity, low gas content and low vapor pressure.
Chemical Composition	%	Ni		Fe	C	Mn		S	Si		Cu
	min	Remaining amount
	max	Remaining amount		0.4	0.152	0.35		0.01	0.35		0.25
Physical Characteristics	Density		8.89g/cm³
	Melting point		1440℃
Minimum mechanical properties of alloys at room temperature	Alloy state		tensile strength Rm N/mm²				Yield Strength RP 0.2 N/mm²			Elongation A5%
	Inconel 200		60-85				15-45			35-55

Material Characteristics

Corrosion Resistance: Outstanding resistance to acids, alkalis, and neutral salts, making it ideal for harsh environments.

Excellent Mechanical Strength: Retains mechanical integrity at high temperatures.

Superior Thermal and Electrical Conductivity: Ideal for heat exchangers and electrical components.

Ductility and Weldability: Easily formed and welded into various shapes without compromising structural integrity.

Applications of Nickel 200 Sheet

Nickel 200 Sheet is widely used in industries requiring high-performance, corrosion-resistant materials:

Chemical Processing: Acid-resistant equipment, tanks, and piping.

Aerospace & Defense: High-temperature structural components.

Marine Industry: Saltwater-resistant components.

Energy Sector: Heat exchangers, power plants, and battery components.

Electronics: High-purity electrical contacts and connectors.

Medical Industry: Surgical instruments and medical device manufacturing.

Why Choose Us？

We are looking for partners around the world to expand our business.

High-purity material certification

Provide third-party test reports on the composition of nickel 200 plate materials (such as ASTM B162 standard) to ensure that the Ni content is ≥99.0% and the carbon content is ≤0.15%, meeting the requirements of corrosion resistance and high temperature applications.

Customized size and shape processing

Support laser/water jet cutting and stamping, provide non-standard sizes (such as ultra-thin plates 0.1mm or ultra-thick plates 50mm), special-shaped parts processing, and reduce customers' secondary processing costs.

Technical solution consultation

Provide material selection support (such as comparing the applicable scenarios of nickel 200 and nickel 201), corrosion resistance data (hydrochloric acid/alkaline environment tolerance curve), and assist customers in optimizing designs.

Welding and forming supporting services

Provide TIG welding process guidance, match welding materials (such as ENi-1 welding rods), solve the problem of thermal crack sensitivity of nickel alloys, and ensure the stability of welded structures.

Reliable Global Supply

With global distribution capabilities, we can provide reliable logistics solutions no matter where the customer is.

Small batch trial production service

Provide free samples or small batch trial production services to help you verify product performance and reduce trial and error costs.

ABOUT US

As a professional manufacturer and supplier focusing on the nickel alloy field, we are committed to providing high-performance nickel 200 plates and all-round technical solutions for global industrial customers. Relying on advanced smelting technology and strict quality control system, we cover the diversified needs from 0.1mm ultra-thin plates to 50mm extra-thick plates, and support deep processing services such as laser cutting and welding forming.

Deeply engaged in aerospace, chemical equipment, new energy and other fields, we have become a trusted nickel alloy technology partner for customers with an 18-month ultra-long warranty and rapid response mechanism to jointly cope with extreme working conditions such as high temperature and strong corrosion.

AS9120

Quality Control

70+

Global Supply

110+

Number Of Employees

50000㎡

Modern Factory

FAQ

1. What are the available sizes and thicknesses?

Our products come in various forms, including plate, sheet, coils, foils, strips, and flats, with thicknesses ranging from 0.1mm to 100mm.

2. Can you provide test certificates?

Yes, all our Nickel 200 products come with Mill Test Certificates (MTC) and comply with industry standards like ASTM B162.

3. Do you offer customization?

Absolutely! We support custom sizes, shapes, and processing to match your exact requirements.

4. What are your payment terms?

We accept T/T, L/C, and negotiable payment options to accommodate your business needs.
