Monel K500 Sheet

Standard:ASTM，JIS，AISI，GB，DIN，EN
Form:Plate,Sheet,Coils, Foils, Strip, Flats
Thickness:0.1 milimeter to 100 milimeter Thk
Technique：Cold rolling, hot rolling, solution, annealing
Customized size and processing are supported
Payment way:T/T, L/C, can be negotitated

Send Inquiry

Download

Product Description

Your Reliable Monel K500 Sheet Supplier & Manufacturer

TSM Technology Co., Ltd is a trusted manufacturer and supplier of Monel K500 Sheet, offering premium-quality nickel alloys to industries worldwide. Our product is known for its excellent corrosion resistance, superior strength, and outstanding durability, making it the ideal choice for aerospace, marine, chemical, and energy applications.

Monel K500 Sheet Introduction

Monel K500 Sheet is a precipitation-hardened nickel-copper alloy that combines the excellent corrosion resistance of Monel 400 with greater strength and hardness. The alloy maintains its properties in extreme environments, making it a preferred choice for industries requiring high-performance materials. With added aluminum and titanium, It exhibits superior mechanical properties, including resistance to seawater corrosion, high temperatures, and chemical exposure.

Plates

Sheets

Strip

Coil

Dimensions:

Thickness：Hot rolled:3.0-180mm，Cold rolled:0.15mm-10mm

Width：10~2000mm

Length：1000mm-6000mm or as customer' s requirement

Finish: 2B, No.1, No.2, No.4, BA, 6K, Mirror Finished, 8K

Standards

ASTM B865/ASME SB-865.

Monel K-500(UNS N05500)
Chemical Composition	ALLOY	%	Ni		C u	Fe		AL	C		Ti	M n		Si	P
	500	min	63		27			2.30			0.35
		max			33	2.0		3.15	0.08		0.85	1.5		0.5	0.01
Physical Characteristics	Density 8.05g/cm³
	Melting point 1288-1343℃
Minimum mechanical properties of alloys at room temperature	Typical mechanical properties			tensile strength Rm N/mm²			Yield Strength RP0.2 N/mm²			Elongation A5%			Test ℃
	Solution treatment			1100			790			20			Normal temperature

Material Characteristics

High Strength & Hardness: Precipitation-hardened for superior mechanical properties.

Corrosion Resistance: Excellent resistance to seawater, acidic, and alkaline environments.

Non-Magnetic: Maintains non-magnetic properties even at low temperatures.

Good Thermal Conductivity: Suitable for high-temperature applications.

Long Service Life: Ensures durability in harsh environments.

Applications of Monel K500 Sheet

Aerospace Industry: Components for aircraft and space applications.

Marine Engineering: Offshore structures, shipbuilding, and propeller shafts.

Chemical Processing: Heat exchangers, reactors, and chemical storage.

Energy Sector: Oil & gas extraction, power plants, and nuclear applications.

Medical Equipment: Surgical instruments and precision engineering parts.

Our Service

We are looking for partners around the world to expand our business.

Customized Solutions

Provide customized nickel plate production services according to your specific needs. Whether it is size, thickness, shape, or special surface treatment requirements.

Precision Tolerances

Our plates are manufactured to precise tolerances, ensuring consistent quality and flatness.

Technical support

Equipped with a professional technical team, we provide you with technical support and consulting services in nickel plate application, processing, welding, etc.

Reliable Global Supply

With global distribution capabilities, we can provide reliable logistics solutions no matter where the customer is.

Processing value-added service

Provide further processing services for nickel plates, such as cutting, punching, welding, surface treatment, etc.

Small batch trial production service

Provide free samples or small batch trial production services to help you verify product performance and reduce trial and error costs.

FAQ

Q: What are the available forms of Monel K500 Sheet?

A: We supply plates, sheets, coils, foils, strips, and flats in thicknesses from 0.1 mm to 100 mm.

Q: What techniques are used in processing Monel K500 Sheet?

A: Our sheets undergo cold rolling, hot rolling, solution treatment, and annealing to ensure optimal performance.

Q: What payment methods do you accept?

A: We accept T/T, L/C, and other negotiable payment terms for your convenience.

Q: Do you provide certification and test reports?

A: Yes, all our products come with material test reports (MTR), mill certificates, and compliance documents.

Contact Us

For more information or to place an order about the Monel K500 Sheet, feel free to reach out to us at info@tsm-technology.com. Our team is here to assist you with any questions or custom requirements you may have.
