Nickel Alloy Plate

Standard:ASTM，JIS，AISI，GB，DIN，EN
Form:Plate,Sheet,Coils, Foils, Strip, Flats
Thickness:0.1 milimeter to 100 milimeter Thk
Technique：Cold rolling, hot rolling, solution, annealing
Customized size and processing are supported
Payment way:T/T, L/C, can be negotitated

Send Inquiry

Download

Product Description

Your Trusted Nickel Alloy Plate Manufacturer & Supplier

TSM Technology Co., Ltd is a leading manufacturer and supplier of Nickel Alloy Plate, offering high-quality, corrosion-resistant, and high-temperature-resistant alloy solutions for demanding industries. With over 14 years of expertise, strict quality control, and international certifications, we ensure premium materials that meet your precise engineering needs.

Nickel Alloy Plate Introduction

Nickel Alloy Plates are high-performance metal sheets made from nickel-based superalloys such as Inconel, Monel, Hastelloy, and Incoloy. These materials are designed to withstand extreme temperatures, corrosion, and mechanical stress, making them ideal for aerospace, energy, chemical processing, and marine applications.

Our products are available in various thicknesses, widths, and surface finishes, tailored to meet diverse industrial requirements. Whether you need standard specifications or customized solutions, TSM provides superior-quality products for high-performance applications.

Specification：

Alloy Type	Material Grade	Standard
Inconel®	600/601/625/718	ASTM B168、AMS 5870、B443、AMS 5599、B670、AMS5596/5597、AMS5542/5598
Hastelloy®	C276/C22/B3	ASTM B435、AMS 5536、B575、B333、B334、AMS 5530
Monel®	400/K500	ASTM B127、AMS 4544、B965
Incoloy®	800/825	ASTM B409、AMS5871、B424
Nickel	200/201	ASTM B162

Customized specifications:

Thickness: 0.5mm - 150mm

Width: 1000mm - 2400mm

Length: 2000mm - 12000mm

Hot rolling/cold rolling process: Thickness tolerance ±0.05mm

Test report: Provide PMI (spectral analysis), UT flaw detection, intergranular corrosion test (ASTM G28)

Traceability: Each plate is laser marked with furnace number, batch number, material code

Technical Specifications

Tensile strength (room temperature): 550MPa - 1450MPa
Elongation (δ5): ≥30% (Inconel 600)
Hardness: HRB 65 - HRC 38
Maximum operating temperature: -200°C to +1200°C
Surface roughness: Ra 0.4μm - 3.2μm (optional)
Surface treatment
2B/BA surface finish (Ra ≤0.8μm)
Sandblasting/pickling/electrolytic polishing (optional)
Cutting:
Water jet cutting (tolerance ±0.1mm)
Laser cutting (thickness ≤25mm)
Heat treatment:
Solution annealing (1050°C ±10°C, rapid quenching)
Stress relief annealing (for welded parts)

Applications of Nickel Alloy Plate

Nickel Alloy Plates are widely used in industries requiring high strength, heat resistance, and corrosion protection:

Aerospace - Turbine blades, engine components

Energy Sector - Gas turbines, nuclear reactors

Chemical & Petrochemical - Heat exchangers, pressure vessels

Marine & Offshore - Shipbuilding, subsea pipelines

Medical Devices - Implantable components, surgical tools

Electronics - High-temperature connectors, circuits

Our Service

We are looking for partners around the world to expand our business.

Customized Solutions

Provide customized nickel plate production services according to your specific needs. Whether it is size, thickness, shape, or special surface treatment requirements.

Quality inspection

Comprehensive quality inspection ensures that each nickel plate meets international standards. At the same time, provide detailed quality inspection reports and certification documents.

Technical support

Equipped with a professional technical team, we provide you with technical support and consulting services in nickel plate application, processing, welding, etc.

Reliable Global Supply

With global distribution capabilities, we can provide reliable logistics solutions no matter where the customer is.

Processing value-added service

Provide further processing services for nickel plates, such as cutting, punching, welding, surface treatment, etc.

Small batch trial production service

Provide free samples or small batch trial production services to help you verify product performance and reduce trial and error costs.

FAQ

Q1: What thicknesses are available for Nickel Alloy Plates?
A: We offer thicknesses ranging from 0.1mm to 100mm, with customizable options available.

Q2: Can you provide material test reports and certifications?
A: Yes, we provide chemical composition reports, mechanical property reports, and non-destructive testing (NDT) reports upon request.

Q3: What is your lead time for bulk orders?
A: Typically, 2-4 weeks, depending on order volume and customization requirements.

Q4: Do you support international shipping?
A: Yes, we ship globally with secure and reliable logistics partners.
